Emhart Heli-Coil® Tangless Inserts eliminate tang break-off and retrieval and are easily adjusted or removed after installation. The Bi-Directional Design installs quickly and easily from either end of the insert. HELI-COIL Tangless inserts have a bi-directional design allowing the insert to be installed from either end Tangless inserts are available as free running & screw locking Types, with all regular coatings.
Heli-Coil Tangless screw lock inserts provide a positive, self-locking torque and comply with both MIL-I-8846 /NASM8846 and NAS1130 requirements. Typical Tangless NAS1130 Parts can be identified as in the product linecard available at this site.
The most productive type of the solid end mills cutters is roughing end milling cutter. They have divided cutting edge and differential pitch. This means smooth running in the cut, good chip evacuation and long life. A record holder in face milling is HFC milling cutter RARU. High feed geometry of inserts and a great number of teeth place it among the most productive tools of its type in the market.
HeliCoil Insertion Tools - Prewinder Type are available as both plain slotted and threaded mandrel captive & non-capitive tools ranging from size M1.6, M2 – M39 and in UNC / UNF category from 1-64 to 1-1/2”. HeliCoil insertion tools comes in variety of configurations such as Threaded Mandrel Type Insertion Tool Threaded Mandrel Prewinder tools having threaded nozzle: Tool is available as both Capitive & Non-Capitive type depending on size & pitch. Plain Mandrel Prewinder tools having threaded nozzle.
Tool is available as both Capitive & Non-Capitive type depending on size & pitch. Plain Mandrel Prewinder tools having threaded nozzle: Tool is available as both Capitive & Non-Capitive type depending on size & pitch. Larger insertion tool sizes are also available & made on request. HeliCoil Prewinder tools are best suited for easy & fatigue free installation of inserts in production line to achieve a high quality of HeliCoil insert installation & prevent jumping of coil threads. Threaded mandrel prewinders are also best recommended for successful installation of screw locking inserts and free running inserts having a fine thread pitch.
HeliCoil Screw Locking Insert as standard is available in Stainless Steel AISI-304/ DTD 734 . Metric series ranges from M2 to M39 & unified series from UNC / UNF 1-64 to 1-1/2 inch. HeliCoil Screw Lock Insert is also available in strip feed or reel mounted form.
HeliCoil Locking Insert provides an exclusive, resilient internal locking thread that grips the bolt and prevents it from loosening under vibration or impact. One or more coils of the HeliCoil insert, having a series of straight segments/ chords, achieve locking action. HeliCoil Locking Insert permits repeated assembly and disassembly and will not relax their grip on the screw even in tough metals such as cast iron, alloy steel, titanium, etc.
HeliCoil Locking Insert positively secures threaded members against loosening caused by vibration and shock. HeliCoil Locking Insert has a high reusable factor permitting frequent removal and reassembly of bolt without appreciable loss of torque. It has positive self-locking torque, complying with NASM8846, MA1565 and MIL-N-25027. It eliminates the usage of lock wiring, lock nuts, lock washers, chemical compounds, plastic pellets/ patches and other locking mechanisms. The HeliCoil Locking Inserts are subjected to extensive tests in tension, torque, shear, vibration and fatigue, conducted by the American & European companies. Its applications include sectors like Aviation & Aerospace, Electronics, Industrial, Automotive and Military.
