DISC MILLING CUTTERS
Disc milling cutter is one of the most productive milling tools. The innovated line of disc milling cutters is based on tangentially clamped indexable cutting inserts. Thus we can offer a productive and reliable solution for wider cut (adjustable milling cutters) and milling cutters for thinner holders (fixed millingcutters).
You should not miss
The fixed milling cutters are not only used for slot milling but also for material division. The milling cutters with flange can mill slots at the bottom of the part. The milling cutters are clamped in the same way as the standard shell end milling cutters. Disc milling cutters without flange can be used independently but also in assembled tools. For independently clamped disc milling cutters we offer FMH4 type arbor, which is universal for all widths of milling cutters offered.
Adjustable disc milling cutters represent a universal solution for slot milling. The exchangeable cartridges are adjustable within 14 to 18.5 mm, 19 to 24.3 mm and 24.5 to 30.5 mm according to the body of milling cutter and cartridge. The milling cutter bodies can also be one-side fitted for milling of one surface. Feed per tooth, or middle thickness of hm chip, which should be between 0.1 to 0.2 mm for fixed and 0.08 to 0.1 mm for adjustable disc milling cutters are also important parameters when choosing the cutting conditions.
DORMER CATALOGUE
PRAMET CATALOGUE
SOLID END MILLING CUTTERS
A wide assortment of solid end mills cutters covers all areas of machined materials. There are versions for all milling operations from roughing to finishing operations including milling cutters with universal use. The most used types of milling cutters are available in several length versions.
You should not miss
The most universal line of the solid end mills cutters is SUMA milling cutters. They have positive cutting geometry and very wear-resistant coating. Such combination enables them to machine in a wide range of materials of P, M, N and S groups.
We offer the tools with theLFMX inserts for middle-deep and deep parting off and grooving. There are also geometries for fine and rough operations as well as inserts with straight and inclined cutting edge in the assortment. The offer of the inserts ranges from 1.6 mm to 6.35 mm.
The most productive type of the solid end mills cutters is roughing end milling cutter. They have divided cutting edge and differential pitch. This means smooth running in the cut, good chip evacuation and long life. A record holder in face milling is HFC milling cutter RARU. High feed geometry of inserts and a great number of teeth place it among the most productive tools of its type in the market.
